Tronic Automatic Transfer Switch 150A

Ask about this product

0 /5.0 (0 reviews)

People are viewing right now

Pricing

Ugx 4,500,000 /pc

100 available

Minimum order qty 1

QTY

Inhouse product

Message Seller

TRONIC Automatic Transfer Switch (ATS) controller uses microprocessor as its core which can precisely monitor voltage (loss of main power). The ATS will start functioning in the following circumstances; loss of power, over voltage, under voltage phase. Additional Information Colour White Amps 150A Voltage AC 230V ± 30% Material Aluminium Additional Information DC power supply: DC(8-35)V between VIN and GND Measured voltage: Rated line voltage 400V; 50Hz/60Hz: 3 phase 4 wire. Range of abnormal power Over voltage threshold: 240~290, 5V. Default: 264 5V. Under voltage threshold: 164~198V, 5V. Default: 172 5V Voltage normal delay: (1~60) seconds. Voltage abnormal delay: (1~60) seconds, default: 5 seconds. Genset start delay: Issued at a default of 5 seconds. Genset start delay: Is set at default 60 seconds. Envoirment conditions: Working Temperature: (-30~+70) C. Humidity: (20~95)%RH. Warranty 1 Year Key Features: TRONIC Automatic Transfer Switch (ATS) controller uses microprocessor as its core which can precisely monitor voltage (loss of main power). The ATS will start functioning in the following circumstances; loss of power, over voltage, under voltage phase.
